18.5" Android Digital Signage & 14" 15.6" 17.3" 21.5" available
Feature
- Support Android8.1 OS or higher
- G+G CTP for excellent experience
- 18.5″ IPS panl with 1366*768 resolution and supports 1080 video
- Support WIFI 802.11 b/g/n, and optional WIIF AC/5G
- Support HDMI port, USB port, Serial port and RJ45 port
- Support USB device mode and USB Host mode
- Support customized logo printing and color for shell based MOQ
- Available to expand EMMC to 32G/64G
- Support front camera 2.0 MP or higher
- Slim design with 75x75mm VESA hole, easy to install
| System Hardware Configuration | CPU | Type | RK3288 Quad-core (optional RK3399) |
| Speed | 1.8GHz | ||
| GPU | Type | Integrated 2D/3D Mali-T764 GPU, up to 600MHz | |
| RAM | DDR3 | 2G | |
| ROM | EMMC | 16G | |
| Operation System | OS Version | Android8.1 | |
| Mechanical | Dimension | 468 x 288 x 38mm | |
| Weight | 3.0Kg | ||
| Device Color | Black (Optional: white & based MOQ 500pcs) | ||
| Shell Material | ABS plastic | ||
| Display | LCD | Screen Size | 18.5″ 16:9 LCD HD panel |
| Active area | 409.8（H)X230.4mm(V) | ||
| Resolution | 1366*768 | ||
| Brightness | 250 cd/m2 | ||
| Contrast ratio | 1000 | ||
| View angles | 85/85/85/85(L/R/U/D) | ||
| TP | Touch Panel | 10 point Capacitive | |
| Others | Camera | Front Camera | 2.0 MP |
| Speaker | built-in | stereo speaker 2*3W | |
| Mic | built-in | ||
| Wall mounting | VESA,75x75mm | ||
| Language | Multi-language | ||
| Media plays | Video format | MPEG-1,MPEG-2,MPEG-4,H.263,H.264,VC1,RV etc. support up to 1080p |
|
| Audio format | MP3/WMA/AAC etc. | ||
| Photo | JPEG, BMP, GIF, PNG | ||
| Data Communication | WIFI | 802.11b/g/n (optional 802.11b/g/n/ac) | |
| Bluetooth | Bluetooth 4.0 | ||
| 3G | 3G USB dongle ext. | ||
| Ethernet | 100M/1000M Ethernet | ||
| Interface | Card slot | SD Card, Support up to 32GB | |
| USB Device | Mini USB OTG | ||
| USB Hostx3 | USB Host 2.0 | ||
| Power Jack | DC power input | ||
| RJ45 | 100M/1000M Ethernet (optional POE) | ||
| HDMI | HDMI output | ||
| Earphone | 3.5mm earphone | ||
| Accessories | User manual | Standard | |
| Power Adaptor | Standard | 12V,3A | |
| Column Bracket | Standard | ||
DF18 is 18.5″ Android based Digital Signage or cheap all in one computers with 10 points Capactive Touch, this terminal is equied with Android8.1 as standard OS, but support higher version based Rockchip3399 processor. To meet most of the applications, WF1852 adopts slim design with 75x75mm VESA hole at the rear of the shell which could be easy to install like fixed mounted on wall or set up on the table with Column Bracket. its17″ IPS panl with 1366*768 resolution. Beside above features, the 2.0 MP front camera and the abondon interfaces like USB, HDMI, serial port, and RJ45 port meets various applications and development. Therefore, it is widely used in Bank, School, hospital, government, restaurant, hotels etc.
For more information, please feel free to contact our sales team: sales@vecoton.com
Thank you for your support
